Professional manufacturer of water & beverage machine
1. Blowing 0.5-1.5 PET common bottle.
2. Durable PLC micro computer controlling system controls time can be accurate to 0.01 seconds.
3. Special recycling installation for high pressure air reduces the energy consumption.
4. The far-infrared heater uses a way of conversion self-rotating heating and the rail revolution makes the heating even, uick and
reliable.
5. Every heating lamp has independent temperature control device, to get ideal perform heating effect.
6. Particular pre-heater design makes perform close while heating. Change space, shorten heating tunnel and reduce energy
consumption according to the bottle size while blowing.
7. Simple installation and starting.
|
Item
|
DT-3
|
DT-4
|
DT-6
|
|
Cavity
|
3
|
4
|
6
|
|
Theory output
|
3300
|
4500
|
6500
|
|
Max.volume
|
2l
|
2l
|
2l
|
|
Light tube power
|
0.75kw
|
0.75kw
|
0.75kw
|
|
Max.heating power
|
12kw
|
24kw
|
40kw
|
|
All electric machine installation
|
18kw
|
25kw
|
35kw
|
|
Work pressure
|
7-9kg/cm2
|
7-9kg/cm2
|
7-9kg/cm2
|
|
Low-pressure gas consumption
|
1000Ltr/min
|
1000Ltr/min
|
1000Ltr/min
|
|
Blow bottle pressure
|
2.6-3.0Mpa
|
2.6-3.0Mpa
|
2.6-3.0Mpa
|
|
Blowing air consuming
|
≥2.4m³/min
|
≥3.2m³/min
|
≥4.8m³/min
|
|
Size of the machine
|
2.7×1.45x2m
|
3.4×1.9x2m
|
3.4×1.9x2m
|
|
Main body weight
|
2000
|
2600
|
3200
|
